- Place of Origin:CN;ZHE
- Type:Core Drill Bit
- Use:Metal Drilling
- Brand Name:CHTOOLS
- Model Number:HMTI
1. Spec.: φ14mm—φ100mm; cutting thickness: 4.5mm
2. Features: imported quality insert with excellent tipping resistance effectively improves overall working efficiency; high cost performance
3. Advantages: special arc-shaped chip flute design to reduce stuck chip and maintain smooth operation
Special sectional cutting function to avoid tipping due to cutting edge hitting against the workpiece
4. Applicable equipment: electric hand drill, percussion drill (rotary), magnetic drill, bench drill, etc.
| TYPE | SIZE ( MM ) | TYPE | SIZE ( MM ) |
| HMTI-10140 | 14*5 | HMTI-A0625S | 5/8"*3/16" |
| HMTI-10150 | 15*5 | HMTI-A0687S | 11/16"*3/16" |
| HMTI-10160 | 16*5 | HMTI-A0750S | 3/4"*3/16" |
| HMTI-10170 | 17*5 | HMTI-A0812S | 13/16"*3/16" |
| HMTI-10180 | 18*5 | HMTI-A0875S | 7/8"*3/16" |
| HMTI-10190 | 19*5 | HMTI-A0937S | 15/16"*3/16" |
| HMTI-10200 | 20*5 | HMTI-A1000S | 1"*3/16" |
| HMTI-10210 | 21*5 | HMTI-A1062S | 1-1/16"*3/16" |
| HMTI-10220 | 22*5 | HMTI-A1125S | 1-1/8"*3/16" |
| HMTI-10230 | 23*5 | HMTI-A1250S | 1-1/4"*3/16" |
| HMTI-10240 | 24*5 | HMTI-A1375S | 1-3/8"*3/16" |
| HMTI-10250 | 25*5 | HMTI-A1500S | 1-1/2"*3/16" |
| …… | …… | HMTI-A1750S | 1-3/4"*3/16" |
| HMTI-10510 | 51*5 | HMTI-A2000S | 2"*3/16" |
| HMTI-10520 | 52*5 | HMTI-A2125S | 2-1/8"*3/16" |
| HMTI-10530 | 53*5 | HMTI-A2250S | 2-1/4"*3/16" |
| HMTI-10540 | 54*5 | HMTI-A2375S | 2-3/8"*3/16" |
| HMTI-10550 | 55*5 | ||
| HMTI-10560 | 56*5 | ||
| HMTI-10570 | 57*5 | ||
| HMTI-10580 | 58*5 | ||
| HMTI-10590 | 59*5 | ||
| HMTI-10600 | 60*5 |
